Single Core Wire UL1429 18AWG 22AWG 24AWG 28AWG 32AWG XLPVC Insulation Copper Conductor Halogen Free Wire Electric Cable Wire
US$ 0.03 -
0.5
/ 1 Meter
Minimum order: 5000
Meters
Get Latest Price
Product Information
View More
Application
Heating, Overhead, Underground, Industrial, Construction, Power, Power Distribution, Telecommunication, Electronics, Home Appliance, Automotive, Marine, Photovoltaic Power
Conductor Material
cooper
Conductor Type
Stranded, Solid
Insulation Material
XLPVC
6 yrs
This supplier has a Global Sources Website for 6 years.
Response Rate:
High
Avg Response Time:
≤24 h
Trade Shows
We exhibited at
3
Global Sources Trade Shows.
View More
Business Type
Manufacturer
,
Exporter,
Trading Company
,
Exporter,
Trading Company
Chat
Follow
Product Information
| Model Number | UL1429 #1989-#2740 | Brand Name | Bort |
|---|---|---|---|
| origin | China | Small Orders | Accepted |
Key Specifications/ Special Features:
Single Core Wire UL1429 18AWG 22AWG 24AWG 28AWG 32AWG XLPVC Insulation Copper Conductor Halogen Free Wire Electric Cable Wire
PRODUCT DESCRIPTION
●Rated temperature：80℃
●Rated voltage：150V
●Reference standard：UL758,UL1581,CSA C22.2No.210.2
●Solid or stranded ,tinned or bare copper conductor 32~16AWG
●XLPVC insulation ,comply with ROHS environmental standard
●Passes UL VW-1,CSA FT1 flame test
●Uniform insulation thickness to ensure easy stripping and cutting
●For general purpose internal wiring of appliance
| CONDUCTOR | INSULATION | Overall diameter (mm) | MAX.COND.RESISTANCE Ω/km,(20℃，DC) | Approx. weight (g/m) | Standard packing (m) | |||
| SIZE | CONSTRUCTION (No./mm) | DIA. (mm) | THICKNESS (mm) | Standard | Tolerance | |||
| 32 | 7/0.08 | 0.24 | 0.31 | 0.90 | ±0.1 | 556 | 1.21 | REEL |
| 32 | 7/0.08 OS-1 | 0.24 | 0.31 | 0.90 | ±0.1 | |||
| 32 | 1/0.20 | 0.2 | 0.31 | 0.85 | ±0.1 | 1.07 | ||
| 30 | 7/0.10 | 0.30 | 0.31 | 0.95 | ±0.1 | 381 | 1.47 | REEL |
| 30 | 7/0.10 OS-1 | 0.30 | 0.31 | 0.95 | ±0.1 | |||
| 30 | 1/0.254 | 0.254 | 0.31 | 0.90 | ±0.1 | 1.32 | ||
| 28 | 7/0.127 | 0.38 | 0.31 | 1.00 | ±0.1 | 239 | 1.84 | REEL |
| 28 | 7/0.127 OS-1 | 0.38 | 0.31 | 1.00 | ±0.1 | |||
| 28 | 1/0.32 | 0.32 | 0.31 | 0.95 | ±0.1 | 1.65 | ||
| 26 | 7/0.16 | 0.48 | 0.31 | 1.10 | ±0.1 | 150 | 2.48 | 610 |
| 26 | 1/0.40 | 0.40 | 0.31 | 1.05 | ±0.1 | 2.21 | ||
| 24 | 11/0.16 | 0.61 | 0.31 | 1.25 | ±0.1 | 94.2 | 3.5 | 610 |
| 24 | 7/0.20 | 0.60 | 0.31 | 1.25 | ±0.1 | |||
| 24 | 7/0.20 OS-1 | 0.60 | 0.31 | 1.25 | ±0.1 | |||
| 24 | 1/0.51 | 0.51 | 0.31 | 1.15 | ±0.1 | 3.05 | ||
| 22 | 17/0.16 | 0.76 | 0.31 | 1.40 | ±0.1 | 60.16 | 4.88 | 610 |
| 22 | 7/0.254 | 0.76 | 0.31 | 1.40 | ±0.1 | |||
| 22 | 7/0.254 OS-1 | 0.76 | 0.31 | 1.40 | ±0.1 | |||
| 22 | 1/0.64 | 0.64 | 0.31 | 1.30 | ±0.1 | 4.43 | ||
| 20 | 26/0.16 | 0.94 | 0.31 | 1.60 | ±0.1 | 38.58 | 6.83 | 610 |
| 20 | 10/0.254 | 0.94 | 0.31 | 1.60 | ±0.1 | |||
| 20 | 7/0.32 | 0.94 | 0.31 | 1.60 | ±0.1 | |||
| 20 | 1/0.813 | 0.813 | 0.31 | 1.50 | ±0.1 | 6.47 | ||
| 18 | 41/0.16 | 1.20 | 0.31 | 1.85 | ±0.1 | 22.98 | 10.24 | 610 |
| 18 | 16/0.254 | 1.20 | 0.31 | 1.85 | ±0.1 | 10.14 | ||
| 18 | 1/1.024 | 1.024 | 0.31 | 1.65 | ±0.1 | 9.23 | ||
| 16 | 26/0.254 | 1.50 | 0.31 | 2.15 | ±0.1 | 15.06 | 15.38 | 610 |
| 16 | 1/1.29 | 1.29 | 0.31 | 1.95 | ±0.1 | 14.12 | ||
FAQ
Q1: Can I get a free sample?
A1: We can provide the existing items samples free in freight collected. If there is any special samples requirement, please contact us for more details.
Q2: How could I pay?
A2: We prefer T/T or L/C at sight. If you prefer other payment terms, please contact us freely.
Q3: What is your packing way? Can I have the customized package?
A3: We have the standard export package. For more details about the customized package, please contact us.
Q4: What is the delivery lead time?
A4: It depends on the order quantities. The mass production lead time is about 7-12 days after receipt of the deposit.
Q5: Are you a factory or a trading company?
A5: We are a factory. We provide all kinds of OEM/ODM services for clients around the world.
Q6: Where is your main market?
A6: We export to the North America, Southeast Asia, Europe, Korea, Japan, and other countries.
Our Services
1. Professional QC and QA team to make sure all products qualified before shipping.
2. Competitive price
3 .Standard package to ensure the safe transportation.
4. Professional service
Why choose us?
1. Production
Qualified production, competitive price, professional service.
2. Technology
Professional R&D team
3. Equipment
With completive testing equipment.
4. Quality
ISO9001:2015/ UL&CUL/ CE/ PSE/ VDE/RoHS/ Reach certificate
Product Certifications
| Certificate Standard |
UL
| ||||
|---|---|---|---|---|---|
| Certificate Image | Click on the picture to see a larger one | ||||
| Certificate Number | E330484 | ||||
| Validity | From 2020/06/28 To 2030/06/18 | ||||
| Issued By | Underwriters Laboratories Inc. | ||||
Note: Not all certifying agents offer online lookup, and some have a lag time for posting new certificates. If you are unable to find a certificate online, contact the certification agency or supplier for further verification.
Shipping Information
| FOB Port | Xiamen | Lead Time | 15–30 days |
|---|---|---|---|
| Weight per Unit | 15.0 Kilograms | Dimensions per Unit | 30.0 x 30.0 x 20.0 Centimeters |
| HTS Code | 8544.49.19 00 | Units per Export Carton | 2.0 |
| Export Carton Dimensions L/W/H | 1.1 x 1.1 x 0.9 Meters | Export Carton Weight | 500.0 Kilograms |
Main Export Markets
| Main Export Markets |
Asia,
Australasia,
Central/South America,
Eastern Europe,
Mid East/Africa,
North America,
Western Europe | ||
|---|---|---|---|
Payment Details
| Payment Method | Telegraphic Transfer (TT,T/T) | ||||
|---|---|---|---|---|---|
