Electronic Wire UL3266 XLPE Insulated Wire 300V Stranded Conductor 10-32AWG Heating cables
US$ 0.012 -
1
/ 1 Meter
Minimum order: 305
Meters
Get Latest Price
Product Information
View More
Management Certification
ISO
Product Certification
UL, ROHS
Color
Black, Red, Yellow, Green, Blue, White, Orange, Purple, Cyan, Copper
Conductor Material
Tinned Copper, Bare Copper
Sample Policy :
Contact us for information regarding our sample policy
6 yrs
This supplier has a Global Sources Website for 6 years.
Response Rate:
High
Avg Response Time:
≤24 h
Trade Shows
We exhibited at
3
Global Sources Trade Shows.
View More
Business Type
Manufacturer
,
Exporter,
Trading Company
,
Exporter,
Trading Company
Chat
Follow
Product Information
| Model Number | UL3266 11 -#8365 | Brand Name | Bort |
|---|---|---|---|
| origin | China | Small Orders | Accepted |
Key Specifications/ Special Features:
Electronic Wire UL3266 XLPE Insulated Wire 300V Stranded Conductor 10-32AWG Heating cables
Rated temperature: 125℃
Rated voltage: 300V
Reference standard: UL758, UL1581, CSA C22.2No.210.2
Solid or stranded, tinned or bare copper conductor 32-10AWG
XLPE insulation, comply with ROHS environmental standard
Passes UL VW-1, CSA FT1/FT2 flame test
Uniform insulation thickness to ensure easy stripping and cutting
For general purpose internal wiring of appliance
| CONDUCTOR | INSULATION | OVERALL DIAMETER (mm) | MAX.COND. RESISTANCE Ω/km (20℃, DC) | APPROX. WEIGHT (g/m) | STANDARD PACKING (m) | |||
| SIZE | CONSTRUCTION (No./mm) | DIA. (mm) | THICKNESS (mm) | MAX.. | TOLERANCE | |||
| 30 | 7/0.10 | 0.30 | 0.40 | 1.10 | ±0.1 | 381 | 1.75 | 610 |
| 28 | 7/0.127 | 0.38 | 0.40 | 1.20 | ±0.1 | 239 | 2.26 | 610 |
| 26 | 7/0.16 | 0.48 | 0.40 | 1.30 | ±0.1 | 150 | 2.94 | 610 |
| 24 | 11/0.16 | 0.61 | 0.40 | 1.40 | ±0.1 | 94.2 | 3.85 | 610 |
| 24 | 7/0.20 | 0.60 | 0.40 | 1.40 | ±0.1 | |||
| 22 | 17/0.16 | 0.76 | 0.40 | 1.60 | ±0.1 | 60.16 | 5.44 | 610 |
| 22 | 7/0.254 | 0.76 | 0.40 | 1.60 | ±0.1 | |||
| 20 | 26/0.16 | 0.94 | 0.40 | 1.80 | ±0.1 | 38.58 | 7.58 | 610 |
| 20 | 7/0.32 | 0.94 | 0.40 | 1.80 | ±0.1 | |||
| 18 | 41/0.16 | 1.20 | 0.40 | 2.10 | ±0.1 | 22.98 | 11.18 | 610 |
| 18 | 16/0.254 | 1.20 | 0.40 | 2.10 | ±0.1 | 11.07 | ||
| 16 | 26/0.254 | 1.50 | 0.40 | 2.40 | ±0.1 | 15.06 | 16.45 | 610 |
| 14 | 41/0.254 | 1.90 | 0.40 | 2.70 | ±0.15 | 9.59 | 23.97 | 305 |
| 12 | 65/0.254 | 2.36 | 0.40 | 3.20 | ±0.15 | 6.07 | 36.55 | 305 |
| 10 | 65/0.32 | 3.00 | 0.40 | 3.80 | ±0.15 | 3.75 | 64.4 | 305 |
FAQ
Q1: Can I get a free sample?
A1: We can provide the existing items samples free in freight collected. If there is any special samples requirement, please contact us for more details.
Q2: How could I pay?
A2: We prefer T/T or L/C at sight. If you prefer other payment terms, please contact us freely.
Q3: What is your packing way? Can I have the customized package?
A3: We have the standard export package. For more details about the customized package, please contact us.
Q4: What is the delivery lead time?
A4: It depends on the order quantities. The mass production lead time is about 7-12 days after receipt of the deposit.
Q5: Are you a factory or a trading company?
A5: We are a factory. We provide all kinds of OEM/ODM services for clients around the world.
Q6: Where is your main market?
A6: We export to the North America, Southeast Asia, Europe, Korea, Japan, and other countries.
Our Services
1. Professional QC and QA team to make sure all products qualified before shipping.
2. Competitive price
3 .Standard package to ensure the safe transportation.
4. Professional service
Product Certifications
| Certificate Standard |
UL
| ||||
|---|---|---|---|---|---|
| Certificate Image | Click on the picture to see a larger one | ||||
| Certificate Number | E330484 | ||||
| Validity | From 2020/06/28 To 2030/06/18 | ||||
| Issued By | Underwriters Laboratories Inc. | ||||
Note: Not all certifying agents offer online lookup, and some have a lag time for posting new certificates. If you are unable to find a certificate online, contact the certification agency or supplier for further verification.
Shipping Information
| FOB Port | Xiamen | Lead Time | 15–30 days |
|---|---|---|---|
| Weight per Unit | 15.0 Kilograms | Dimensions per Unit | 30.0 x 30.0 x 20.0 Centimeters |
| HTS Code | 8544.49.29 00 | Units per Export Carton | 500.0 |
| Export Carton Dimensions L/W/H | 1.1 x 1.1 x 0.9 Meters | Export Carton Weight | 500.0 Kilograms |
Main Export Markets
| Main Export Markets |
Central/South America,
Eastern Europe,
Mid East/Africa,
North America,
Western Europe,
Asia,
Australasia | ||
|---|---|---|---|
Payment Details
| Payment Method | Telegraphic Transfer (TT,T/T) | ||||
|---|---|---|---|---|---|
