DJI Matrice 4TD

Advanced Thermal Drone for Dock 3 Operations

The DJI Matrice 4TD is a high-performance thermal drone engineered to work seamlessly with the DJI Dock 3. Equipped with a powerful infrared camera, precision telephoto lens, and intelligent flight features, it delivers automated, reliable missions even in the most demanding environments. With IP55 weather resistance and up to 54 minutes of flight time, the M4TD sets a new benchmark for thermal operations, inspections, and emergency response.

Imaging Payloads

• 640 × 512 resolution, f/1.0, ~53 mm equivalent
• Infrared super-resolution up to 1280 × 1024
• UHD Gain Mode support coming in future Dock 3 update
• Thermal Camera
• 1/1.5-inch CMOS, 48 MP
• f/2.8, ~168 mm equivalent
• 4× pixel count vs. M3D, 2× zoom improvement
• Tele Camera
• 1/1.3-inch CMOS, 48 MP
• f/2.8, ~70 mm equivalent
• Mid-Tele Camera
• 1/1.3-inch CMOS, 48 MP
• f/1.7, ~24 mm equivalent
• Wide-Angle Camera
• Range: ~1800 m (5905 ft)
• Accuracy: 0.2 + 0.005 × D (m)
• Laser Rangefinder
• 6° FOV, up to 100 m illumination range
• NIR Auxiliary Light

Enhanced Flight Capabilities

• Dock 2: Up to 51 min
• Dock 3: Up to 54 min
• Extended Flight Duration
• 7× tele camera tilts up to 80° for bridge and overhead asset inspection
• Upward Inspection
• Maintains safe, consistent altitude over variable landscapes
• Dynamic Terrain Following
• M4D & M4TD clarify visuals in low light
• 7× tele lens offers black-and-white night scene for distant clarity
• Night Scene Mode

Intelligent Functions

• Onboard Relay – One drone can act as a signal relay for another, extending range in complex environments.
• Smart Detection – Identifies people, vehicles, and boats in real time, with automated FlightHub 2 alerts.
• Smart Track – Locks onto and follows moving targets automatically.
• Automated Routes – Detects and logs objects along preset waypoints.
• Change Detection – Compares new and historical imagery to highlight changes.
• Mouselook – Smooth gimbal navigation via mouse input for simplified control.
• Select & Zoom – Instantly zoom in on chosen objects for detailed analysis.

AI & Developer Tools

The M4TD supports custom AI detection models, powered by up to 10 TOPS onboard computing.

• Train detection models using DJI’s developer platform.
• Validate with real-world or simulated datasets.
• Deploy online or offline across assigned drone serials.

Data Security & FlightHub Integration

• FlightHub 2 Integration – Stream live data, receive detection alerts, and configure missions.
• Data Security – Backed by ISO-certified AWS servers in the US and EU.
• On-Premises Hosting – From Q2 2025, FlightHub 2 can run on dedicated servers for complete data control.

Why Choose the Matrice 4TD?

With thermal imaging, extended endurance, and intelligent autonomy, the DJI Matrice 4TD is ideal for:

• Infrastructure inspections
• Public safety & emergency response
• Search & rescue
• Night operations & surveillance
• Long-duration automated missions with DJI Dock 3
