Global Sources Hong Kong Shows/Product List/5G Panel Directional 698-3800MHz indoor Wall Mount Antenna
5G Panel Directional 698-3800MHz indoor Wall Mount Antenna
Product Information
Model Number
AC-D7038W08
Brand Name
NONE
Origin
China
Small Orders
Accepted
Key Specifications/ Special Features
| Electrical | |
| Frequency Range | 698-960/1710-3800MHz |
| F/B Ratio | ＞12/18dB |
| Gain | 5/7dBi |
| V.S.W.R | ≤2.0 |
| Radiation | Direction |
| Horizontal Beam width | 68° |
| Vertical Beam width | 58° |
| Polarization | Vertical |
| Lightning Protection | DC Grounded |
| Maximum Input Power | 50W |
| Impedance | 50Ώ |
| Connector | N Female |
| Cable Type | RG58U |
| Cable Length | 30cm |
| Antenna Radome Material | ABS |
| Mount way | Wall Mount |
| Diameter of Installation Pole | Ø30-Ø50mm |
| Mechanical | |
| Dimensions | 207x180x45mm |
| Weight | 500g |
| Rated wind velocity(m/s) | 60m/s |
| Operating Temperature | -40℃ to+70℃ |
| RoHS Compliant | YES |
| Electrical | |
| Frequency Range | 698-960/1710-3800MHz |
| F/B Ratio | ＞12/18dB |
| Gain | 5/7dBi |
| V.S.W.R | ≤2.0 |
| Radiation | Direction |
| Horizontal Beam width | 68° |
| Vertical Beam width | 58° |
| Polarization | Vertical |
| Lightning Protection | DC Grounded |
| Maximum Input Power | 50W |
| Impedance | 50Ώ |
| Connector | N Female |
| Cable Type | RG58U |
| Cable Length | 30cm |
| Antenna Radome Material | ABS |
| Mount way | Wall Mount |
| Diameter of Installation Pole | Ø30-Ø50mm |
| Mechanical | |
| Dimensions | 207x180x45mm |
| Weight | 500g |
| Rated wind velocity(m/s) | 60m/s |
| Operating Temperature | -40℃ to+70℃ |
| RoHS Compliant | YES |
