ATVs for off-roading

Chonghong Industries Ltd’s CHDYTA230120 is an 800cc shaft-driven ATV with a manual gearbox. It has a maximum speed of 90kph and is available with 4-wheel drive. It has LED front and rear lights, EFI ignition, double wishbone front and rear suspension, and front and rear disc brakes. Front and rear tire sizes are 960 and 920mm.

New Gen Tech Global Cooperation Ltd offers the CP-10.0, an electric ATV with a 4-stroke 110cc engine. This vehicle has a CDI ignition, automatic transmission, and maximum torque and power of 5.5Nm at 5,000rpm and 3.6kW at 7,500rpm. It also has a 12V, 4Ah battery, front and rear suspensions, drum or disc brakes and a 3.2L fuel tank.

The TR1000UTV is an ATV with a water-cooled V-type engine having an 800cc capacity, 91mm bore diameter, 61.5mm stroke distance and 10:1 compression ratio. Its maximum power and torque are 41kW at 6,500 to 7,000rpm and 61 N⋅m at 6,002rpm. Fuel tank capacity is 27.5L.

This ATV, made by Fujian Hua Min Group, has a 4,500mm minimum turning radius, 2,850mm wheelbase and 320mm ground clearance. Overall dimensions are 3,590mmx1,660mmx1,960mm.

A 400cc ATV with a load capacity of 345kg, the 00098776 offered by Mycanna Inc. has 2WD and 4WD variants, hydraulic disc brakes, 12in CST tires, 12in alloy rims, EPS and a manual gear shift.

Zhejiang Lianmei Industrial Co. Ltd’s LMATV-110M-5223 is an ATV with a single-cylinder, 4-stroke 110cc engine, producing 5.2kW maximum power at 7,500rpm. It has 52.4mm bore and 49.5mm stroke. Top speed is 40kph.

This vehicle, with a CDI ignition, 2.3L fuel tank and 12V, 4 or 5Ah battery, has a single rear disc and dual drum front brakes. It is fitted with 16x8-7 front and rear tires. Wheelbase is 96cm. Seat height and ground clearance are 67 and 11cm.

Chonghong Industries Ltd’s CH-BS250AU-29B is a manual-transmission ATV with a water-cooled single-cylinder engine, PZ30 carburetor, Q195 steel tube welded frame painted black, and 23x7.0-10 front and 22x10-10 rear tires. This off-roader has a single front rocker arm, rear integral suspension, hydraulic shock absorption, and front and rear bumpers and shelves. Weight is 244kg. An order of one unit is accepted and has a lead time of 10 to 60 days.

This 471cc ATV from Fujian Hua Min Group (Trantek Industries Co.), the TR500UTV, has a four-stroke single-cylinder engine, PD36J carburetor, CDI system, electric starter, drivetrain axle and CVT transmission. This liquid-cooled engine, with an 84.5mm bore and 84mm stroke, has 17.5kW maximum power at 5,500 to 6,000rpm and 32N.m maximum torque at 4,000 to 4,500rpm. More powerful models are also available. An order of one unit is welcome. Lead time is 30 to 40 days.

Suitable for farm work, the NGT-U02-2 from New Gen Tech Global Cooperation Ltd has a 150, 200 or 300cc automatic-transmission and reverse engine with electric start, CDI system, disc front and rear brakes, double swing arm front suspension, air chamber shock absorbers in rear suspension, 9L fuel tank and a 12V, 9Ah battery. Front tire size is 165/70-10 and rear 225/40-10. Vehicle dimensions are 235x120x153cm. This CE-approved ATV has a load capacity of 400kg. An order of one unit has a 15- to 20-day lead time.

Chongqing Peak Industry Co. Ltd offers a primary sheave assembly compatible with Hisun ATVs and UTVs. The ATV02403 has an outer diameter of 191.5mm. The manufacturer part numbers are 21210-F39-0000, 324700005 and 21210-004-0000 for the clutch cover, 21300-F39-0000 for the primary and 21400-F39-0000 secondary clutches and 21230-F39-0000 and 21200-004-0000 for the clutch carrier. The supplier requires a minimum order of 1,000 pieces. Lead time is two to 10 days.

The 18"X9.50-8 from Qingdao Yuntong Industry Co. Ltd is a tubeless ATV tire with a steel rim. It is also available in 15inx6.00-6, 16inx6.50-8, 16inx7.50-8, 18inx6.50-8, 20inx8.00-8, 23inx9.50-12 and 19inx7-8. An order of at least 500 pieces is required. Delivery is in 20 to 30 days.

A 16x6.50-8 tubeless tire for ATVs and golf carts, Qingdao Yufeng Machinery and Equipment Co. Ltd’s YF1605-0061 can carry loads of up to 300kg. It is made of rubber, measures 390mm in diameter and 150mm in width, and weighs 5kg. Hub length is 100mm and bearing holes are 20 and 25mm. MOQ is 500 pieces and lead time 30 to 45 days.
